散热：大功率LED散热器的散热问题得到完美解决，填补了大功率散热器的市场空白，装配更简便，结构更坚固，散热性能更好；

U型支架∶圆形支架调节点，角度可自由调节；

散热原理∶采用航空合金主动式鳍片散热技术，以优异的导热性将光源辅射热量传导至鳍片上，达到快速降低光源温度，延长光源使用寿命的效果；

灯罩呼吸器设计：防水的同时又清除雾气，避免凝霜，提升产品品质，延长使用寿命；

防眩透镜∶防眩透镜的透光率高达96%，发光的角度可选25°、45°、60°、90°、100°；

电缆布线,快捷方便。

Heat dissipation: The heat dissipation problem of high-power LED radiator is solved perfectly, filling the market gap of high-power radiator, easier assembly, stronger structure, better heat dissipation performance;

 U bracket: circular bracket adjustment point, Angle can be adjusted freely;

 heat dissipation principle: The use of aviation alloy active fin heat dissipation technology, with excellent thermal conductivity of the light source auxiliary heat conduction to the fin, to quickly reduce the temperature of the light source, extend the service life of the light source effect;

lampshade respirator design: waterproof and clear fog, avoid frost, improve product quality, prolong service life;

anti-glare lens: anti-glare lens transmittance up to 96%, luminous Angle can be selected 25°, 45°, 60°, 90°, 100°;

Cable wiring, fast and convenient.be used as needed.

本司已通过ISO9001:2015国际质量体系审核认证,产品严格执行ISO9001国际质量管理体系标准生产，确保产品质完全达到国家标准和设计要求；

凡购买本司所生产的产品，均可享受质量三包服务，产品质保五年，具体相关项目详见产品保修卡；

在质保期内，光衰大于15%。我公司免费更换新灯；

本公司产品货期均为15个工作日左右，本司承诺15个工作日内货到现场。

The company has passed ISO9001:2015 international quality system audit certification, products strictly implement the ISO9001 international quality management system standards, to ensure that the quality of products fully meet the national standards and design requirements;

If you buy the products produced by our company, you can enjoy three guarantees of quality service, and the product quality guarantee is five years. Please refer to the product warranty card for specific items；

During the warranty period, the light decline is greater than 15%. My company free replacement of new lights;

The delivery time of the company's products is about 15 working days, and the company promises to deliver the goods to the site within 15 working days.

安装前必须检查实际使用条件与灯具铭牌上所列参数是否相符。

安装前请先按照灯具铭牌参数进行通电点亮检测，确保灯具无质量问题后再进行安装。

安装前必须根据本产品所提供的安装方式结合现场使用环境和照明需求，来确定灯具的安装位置和安装方式，确保安装牢固可靠。

将备好的电缆线与灯具的输入电缆线按火线（棕色）、零线（蓝色）、地线（黄绿色）对应连接，确保连接牢固，并在连接处做好绝缘和防水措施。

将电缆线输入端接通相应电压的电源既可照明。

Before installation, it is necessary to check whether the actual operating conditions are in conformity with the parameters listed on the lamp nameplate.

Before installation, please test the lighting according to the parameters of the lamp nameplate to ensure that there is no quality problem before installation.

Before installation, it is necessary to determine the installation location and mode of the lamps according to the installation mode provided by the product, in combination with the on-site use environment and lighting requirements, so as to ensure that the installation is firm and reliable.

Connect the prepared cables with the input cables of lamps and lanterns according to the corresponding fire (brown), zero (blue) and ground (yellow-green) wires, so as to ensure that the connection is firm, and make good insulation and waterproof measures at the connection.

The input end of the cable can be connected to the power supply of the corresponding voltage to illuminate.

运输时需将灯具装在所配备的纸箱内，并加装泡沫减震。

使用时，灯具表面有一定的温升，属于正常现象。

电源电压在规定电压的范围内可正常工作，电源电压过高会损坏灯具；电压过低，会造成灯具无法正常启动。

灯具必须可靠接地。

When transporting, the lamp should be installed in the carton equipped with foam shock absorption.

When using, the surface of the lamp has a certain temperature rise, which is a normal phenomenon.

The power supply voltage can work normally in the rated voltage. If the power supply voltage is too high, the lamp will be damaged; if the voltage is too low, the lamp will not start normally.

The luminaire must be reliably grounded.
